Unlocked Sim Card 5G Mobile WiFi 6 Hotspot L70MB

Dual Bands 5G Portable Router L70MB

● L70MB is a superior 5G wireless routing product that uses UNISOC's professional 5G intelligent chip to provide download speeds 10 times faster than 4G networks and stable and reliable network performance.

● The application of WiFi 6 enhances the throughput and anti-interference ability of WiFi signals. Its DBDC dual band concurrency feature enables multi-user, long-distance, and high-speed WiFi experience.

● The high-density and large battery capacity of 5000mAH provides a safe and long-lasting service life; Supports up to 32 terminal connections for mobile phones, laptops, tablets, and other devices.

Features

• UNISOC 5G intelligent chip has excellent quality
• WiFi 6 high-speed internet access
• 5000mAH large capacity persistent standby
• DBDC dual band concurrent powerful performance

Product Status:

• Unlocked Sim Card
• 100% New Device
• Colors: Orange/White/Black/Grey. Random Shipment

5G MiFi L70MB Specification

Platform

• CPU: UDX710, Dual core ARM Cortex-A55 1.35GHz
• System: Linux

Memory

• RAM: 4Gb, LPDDR4X
• ROM: 2Gb, NAND

Radio Frequency

● Wireless Access: 5G NR, TDD-LTE, FDD-LTE, WCDMA

● 3GPP: R15

● Antenna: 4G LTE antenna 1T2R & 5G antenna 1T4R, 2-3dBi

● CA: B1+B3 B1+B1 B3+B3 B39+B41 B39+B39 B40+B40 B41+B41

● Throughput rate

• HSDPA: 42.2Mbps (download) (Category 24)
• HSUPA: 11Mbps (Upload) (Category 7)
• WCDMA: 384Kbps (download) / 384Kbps (upload)
• LTE FDD: 300Mbps (download) / 50Mbps (upload)
• LTE TDD: 260Mbps (download) / 30Mbps (upload)
• 5G NR TDD: 2Gbps (download) / 500Mbps (upload)

● Frequency Bands Support

• WCDMA/HSPA: B1
• TDD-LTE: B34/38/39/40/41
• FDD-LTE: B1/B3/B5/B8

• 5G NR: FDD: N1/N3/N28, TDD:N41/N78

● Output Power

• Class 3 (24 dBm +1/-3 dB), WCDMA
• Class 3 (23 dBm ±2 dB), LTE
• Class 3 (23 dBm ±2 dB), 5G NR

WiFi 6 5GHz

● Protocol: IEEE 802.11 a/b/g/n/ac/ax

● Bandwidth: 20/40/80MHz

● TX/RX: 1T1R

● Debugging Method: OFDMA

● Antenna type: Built in antenna

● Antenna gain 2-3dBi

● Number of terminals: Max 32

● Receiver Sensitivity

• MCS9: -63dBm@10% PER
• MCS7: -68dBm@10% PER
• 54M: -70dBm@10% PER
• 11M: -83dBm@8% PER
• 6M: -88dBm@10% PER
• 1M: -90dBm@8% PER

● Transmission Power

• 16dBm(Max) in 11b mode
• 14dBm(Max) in 11g mode
• 14dBm(Max) in 11n mode
• 13dBm(Max) in 11ax mode

● Throughput Rate

• 11ax: 600.4Mbps
• 11ac: 433/390/325…32.5Mbps
• 11g: 54/48/36/24/18/12/9/6 Mbps
• 11b: 11/5.5/2/1 Mbps
• 11n: 150 Mbps /…/6.5Mbps

WiFi 6 2.4GHz

● Protocol: IEEE 802.11 b/g/n/ax

● Bandwidth: 20/40MHz

● TX/RX: 1T1R

● Debugging Method: OFDMA

● Antenna type: Built in antenna

● Antenna gain 2-3dBi

● Number of terminals: Max 32

● Receiver Sensitivity

• Same With 5GHz

● Transmission Power

• Same With 5GHz

● Throughput Rate

• 11ax: 286.8Mbps@TX and 229.4Mbps@RX
• 11g: 54/48/36/24/18/12/9/6 Mbps
• 11b: 11/5.5/2/1 Mbps
• 11n: 150 Mbps /…/6.5Mbps

Hardware

• Button: Power, WPS, Reset
• Indicator: Power, 4G, 5G, WiFi
• USB: Type-C
• Battery: 5000mAh, removable
• Charge: 5V/2A
• SIM: 1.8V/3.0V USIM
• Size: L136*W72*H15.7mm
• Weight: 140g

Software

● Language: English Supported

● Protocol Stack: TCP/UDP/HTTP/PING/HTTPS/FTPS/MQTT/MMS

● Sim Card: PIN/PUK Manage

● IP Protocol: IPV4/IPV6

● VPN: L2TP, PPTP

● Support

• APN settings
• Band lock
• PCI lock
• Cell lock
• Carrier SIM lock
• DHCP lock
• IP filtering
• MAC filtering
• TR069
• AT command
• FOTA
• RNDIS
• WebGUI

● WiFi

• Wi Fi SSID settings
• Encrypt WPA2-PSK, WPA-PSK
• SSID Broadcast
• Supports 32 or more users

● Statistics

• Network Status
• Networking duration
• System running time
• Equipment status
• DHCP client list

● Maintenance

• Time synchronization settings
• Restart
• Restore factory settings
• Restore/Backup Configuration Files
• FOTA upgrade

● System Log

• Operation Log
• Operation log
• Log management

● Temperature

• Working temperature -10~+45 ℃
• Storage temperature -30~+60 ℃
• Humidity: 5% to 95% (no condensation)
