5G NR 4G LTE Portable WiFi Hotspot JC09 With Sim Card Slot

Powerful 5G Connectivity with Ultra-Fast Speeds

Experience blazing-fast internet with this 5G portable WiFi device, featuring theoretical download speeds of up to 2Gbps (5G NR) and 500Mbps upload speeds. For 4G LTE networks, enjoy smooth browsing with 300Mbps download and 50Mbps upload speeds. Whether for work, streaming, or gaming, this device ensures seamless, high-speed connectivity anywhere.

Cutting-Edge WiFi 6 Support & Broad Compatibility

Equipped with WiFi 6 (802.11ax) and backward compatibility with 802.11 a/b/g/n/ac protocols, this portable router delivers faster, more stable connections for multiple devices. Enjoy reduced latency, higher capacity, and improved battery life for connected devices like laptops, smartphones, and tablets.

High-Capacity 6000mAh Battery for All-Day Use

Stay connected longer with a massive 6000mAh built-in battery, providing extended usage without frequent recharging. Perfect for travel, remote work, or outdoor adventures, this device keeps you online for hours on a single charge.

Advanced UDX710 CPU by Unisoc for Reliable Performance

Powered by the Unisoc UDX710 chipset, this 5G hotspot ensures efficient processing, low power consumption, and stable network performance. The robust CPU handles high-speed data transmission effortlessly, making it ideal for bandwidth-heavy tasks.

Convenient USB Type-C Port for Easy Charging & Versatility

The USB Type-C interface offers fast charging and broad compatibility with modern cables and adapters. Use it as a portable power bank (if supported) or connect to other devices for flexible networking options.

Compact & Travel-Friendly Design

Designed for portability, this 5G WiFi hotspot fits easily in pockets or bags, ensuring high-speed internet on the go. Ideal for business travelers, digital nomads, and remote workers who need reliable connectivity anywhere.

5G Mobile WiFi JC09 Specifications

Platform

• CPU: UDX710, Dual core ARM Cortex-A55 1.35GHz
• System: Linux

Product Status

• 100% New Device
• Support English
• Unlocked Sim Card Network
• Colors: White/Black/Grey. Random Shipment

Memory

• RAM: 4Gb, SIP LPDDR4X
• ROM: 2Gb, External NAND

Radio Frequency

● 3GPP: R8, R9...,R15

● Throughput rate

• HSDPA: 42.2Mbps (DL) (Category 24)
• HSUPA: 11Mbps (UL) (Category 7)
• WCDMA: 384Kbps (DL) / 384Kbps (UL)
• LTE FDD: 300Mbps (DL) / 50Mbps (UL)
• LTE TDD: 260Mbps (DL) / 30Mbps (UL)
• 5G NR TDD: 2Gbps (DL) / 500Mbps (UL)

● LTE ANT: 1T2R

● 5G ANT: 1T4R

● WCDMA/HSPA: B1

● TDD-LTE: B34/38/39/40/41

● FDD-LTE: B1/B3/B5/B8

● CA: B1+B3, B1+B1, B3+B3, B39+B41, B39+B39, B40+B40, B41+B41

● 5G NR: FDD: N1/N3/N28

● 5G NR TDD: N41/N78

● NR ENDC: B3+N41, B39+N41, B1+N78, B3+N78, B5+N78, B8+N78

● Output Power

• Class 3 (24 dBm +1/-3 dB), WCDMA Bands
• Class 3 (23 dBm ±2 dB), LTE Bands
• Class 3 (23 dBm ±2 dB), 5G NR Bands

Software

● Protocol: TCP/UDP/HTTP/PING/MQTT

● IP4/IP6: Support

● Web Graphical Interface: Support

● Security: WPA/WPA2-Personal

● RNDIS: Support

● FOTA: Support

● Language: English

Hardware

● Button: POWER, RESET

● IO: TYPE C

● Sim: NANO  SIM

● Battery: 6000mAh

● Charge: 5V/2A

● LED:

• Power, 3 colors
• 4G, 3 colors
• 5G, 3 colors
• WIFI, 3 colors

Wi-Fi 6

● Chips: AIC8800DW+AIC8800D80P, Dual bands 2.4GHz/5GHz

● WiFi Protocol: 802.11 a/b/g/n/ac/ax

● WiFi Antennas: 1x1

● Transmission Power:

• 16dBm(Max) in 11b mode
• 14dBm(Max) in 11g mode
• 14dBm(Max) in 11n mode
• 13dBm(Max) in 11ac mode
• 13dBm(Max) in 11ax mode

● Sensitivity:

• MCS11:-58
• MCS9: -63dBm@10% PER
• MCS7: -68dBm@10% PER
• 54M：-70dBm@10% PER
• 11M：-83dBm@8% PER
• 6M：-88dBm@10% PER
• 1M：-90dBm@8% PER

● Data Rate

• 11ax: 600/540/480…36Mbps (Auto Rate Sensing)
• 11ac: 433/390/325…32.5Mbps (Auto Rate Sensing)
• 11n: 150 Mbps /…/7.2Mbps (Auto Rate Sensing)
• 11g: 54/48/36/24/18/12/9/6 Mbps (Auto Rate Sensing)
• 11b: 11/5.5/2/1 Mbps (Auto Rate Sensing)

Electrical

● ESD: contact ±6k, air ±10K

● EOS: VBAT 200V , VBUS 200V

● Operate Temperature:  -20 ~ +50℃

● Storage Temperature:  -30 ~ +70℃

Authentication

CCC/ROHS/FCC/CE

Package

• JC09 device *1
• Battery: 6000mAh, Removable *1
• Warranty certificate in Chinese *1
• User's Manual in Chinese *1
