Wireless Sharing Router Dock Station Huawei AF23 LTE 4G 3G

Available: In Stock
$29.90 USD
  • 100% Unlocked Sharing Dock for Worldwide Use
  • Wi-Fi Offload solution
  • Ethernet Router Mode, Access Point Mode, and Repeater Mode
  • 4G LTE, DC-HSPA+, HSUPA, HSDPA, WCDMA amp
  • WiFi 802.11n 2*2 Better WiFi signal
  • Support LTE and 3G USB dongles
  • Wi-Fi 802.11n 2*2 Better WiFi signal
  • Up to 300Mps transmission
  • Compact pocket size
  • Easy to connect
  • Several working modes

Interface: 1 x RJ45 for 10/100
Antenna: 2 x internal antennas
WPS Button
Dimension: 80 x 50 x 18 mm
Operating Frequency: 2.4GHz
Power: 5 V with max. 2.0 A

Ethernet Router Mode: AF23 connects to the modem through a network cable and shares a wireless network. Your smartphone, tablet, laptop, and other portable wireless devices can access the internet.
LTE/3G Sharing Mode: AF23 could be used as an LTE/3G wireless router. After plugging the LTE/3G USB Dongle, your wireless device can access the internet. It is easy to setup.
USB Storage Sharing Mode: USB Flash memory can be plugged into AF23 that your mobile devices can access the data in the USB Flash memory.

Huawei AF23, 3G/ 4G USB Modem support list:
E3131s-1, E353u-1, E392u-92, E173s-2, E303Cs-6, E3231Ws-1, E303s-1, E3131s-2, E353u-2, E397Bu-501, ,E173s-3, E303s-1, E3256s-2(V2R2), E3131s-3, E353u-2, E398u-1,E173s-6, E303s-,2 E3276s-150, E3131s-6, E353u-6, E398u-15, E173s-65, E303s-3 , E353Au-2, E3131s-65, E367u-1 , K5005, E173u-1, E303s-6, E353Tu-6,E353s-1, E367u-2, E173Bu-1, E173u-2, E303s-63, E353Ws-1,E353s-1, E367u-8, E173Cu-2, E173u-3, E303s-65, E353Ws-2,E353s-2, E392u-12, E173Du-1, E173u-6, E303u-1, E353Wu-1,E353s-6, E392u-21, E173Eu-1, E173u-63, E303u-2, E397Bu-502,E353s-81, E392u-511, E173s-1, E173u-81, E303u-6, EC156
Huawei E3372, E3272, E397 / E392 / E3276 / E398 / E372 / E3251 / E368 / E3131 / E369 / E182E/ 173 / E303 / Vodafone K5005 / K4605 / K4505 / K4511 / K3806 / K5006 / E3131s-1/ E353u-1/ E392u-92

Package included:
One Huawei AF23
One USB cable
(USB Modem is not included, we will ship only Huawei AF23 Sharing Dock)

The unlocked Huawei AF23 is compact enough to be carried in your bag. It comes with a USB port, four LED indicators, ethernet and micro-USB ports on the sides, and a reset button on the base. With the AF23, you can let 3G modem or 4G LTE modems to work as a 3G/4G router by simply plug the 3G/4G dongle into it. It is a good tool to enable you to share a 3G or 4G mobile network with numerous WiFi devices. Huawei af23 all sides. The AF23 Huawei has two antennae and boasts up to 300Mbps data transmission. It supports 802.11b/g/n, up to 32 wireless connections, and wireless encryption of WEP, WPA, WPA2, TKIP, and AES. This Huawei dock is so powerful that it could operate with 3 different modes: ethernet adapter mode, repeater mode, and LTE sharing mode. In repeater mode, just choose a wireless signal you want to enhance on the FW page then the AF23 will extend its signal coverage. The ethernet adapter mode can connect any Ethernet-enabled device to your wireless home network with LTE AF23 dock. The LTE sharing mode can let your LTE mobile modem to works as a 4G mobile hotspot.
After a long time, HUAWEI offered a new router again– the AF23, which can help a number of users to surf the Internet with Huawei 3G & 4G surf sticks via LAN or WLAN. Huawei AF23 has no built-in modem, so it must operate with a USB surf stick. We must pay attention to the highest possible speed of the HUAWEI AF23: the amazingly small router provides speeds of up to 300 Mbit/s over Wi-Fi and it’s also suitable for excellent Huawei LTE sticks.
Huawei AF23 is not as expensive as a wireless router. Huawei AF23 is not integrated with a battery that keeps the price low, but the HUAWEI AF23 can’t work as a mobile 4G router like HUAWEI E5776. So it’s better to use the HUAWEI AF23 as a stationary router. The English Short Guide describes the basic features, no further information is provided.
Huawei AF23 supports two modes of operation:
Work as a pure access point with the DSL or cable connection via WAN port on the back


  • 100% Unlocked Sharing Dock for Worldwide Use
  • Wi-Fi Offload solution
  • Ethernet Router Mode, Access Point Mode, and Repeater Mode
  • 4G LTE, DC-HSPA+, HSUPA, HSDPA, WCDMA amp
  • WiFi 802.11n 2*2 Better WiFi signal
  • Support LTE and 3G USB dongles
  • Wi-Fi 802.11n 2*2 Better WiFi signal
  • Up to 300Mps transmission
  • Compact pocket size
  • Easy to connect
  • Several working modes

Interface: 1 x RJ45 for 10/100
Antenna: 2 x internal antennas
WPS Button
Dimension: 80 x 50 x 18 mm
Operating Frequency: 2.4GHz
Power: 5 V with max. 2.0 A

Ethernet Router Mode: AF23 connects to the modem through a network cable and shares a wireless network. Your smartphone, tablet, laptop, and other portable wireless devices can access the internet.
LTE/3G Sharing Mode: AF23 could be used as an LTE/3G wireless router. After plugging the LTE/3G USB Dongle, your wireless device can access the internet. It is easy to setup.
USB Storage Sharing Mode: USB Flash memory can be plugged into AF23 that your mobile devices can access the data in the USB Flash memory.

Huawei AF23, 3G/ 4G USB Modem support list:
E3131s-1, E353u-1, E392u-92, E173s-2, E303Cs-6, E3231Ws-1, E303s-1, E3131s-2, E353u-2, E397Bu-501, ,E173s-3, E303s-1, E3256s-2(V2R2), E3131s-3, E353u-2, E398u-1,E173s-6, E303s-,2 E3276s-150, E3131s-6, E353u-6, E398u-15, E173s-65, E303s-3 , E353Au-2, E3131s-65, E367u-1 , K5005, E173u-1, E303s-6, E353Tu-6,E353s-1, E367u-2, E173Bu-1, E173u-2, E303s-63, E353Ws-1,E353s-1, E367u-8, E173Cu-2, E173u-3, E303s-65, E353Ws-2,E353s-2, E392u-12, E173Du-1, E173u-6, E303u-1, E353Wu-1,E353s-6, E392u-21, E173Eu-1, E173u-63, E303u-2, E397Bu-502,E353s-81, E392u-511, E173s-1, E173u-81, E303u-6, EC156
Huawei E3372, E3272, E397 / E392 / E3276 / E398 / E372 / E3251 / E368 / E3131 / E369 / E182E/ 173 / E303 / Vodafone K5005 / K4605 / K4505 / K4511 / K3806 / K5006 / E3131s-1/ E353u-1/ E392u-92

Package included:
One Huawei AF23
One USB cable
(USB Modem is not included, we will ship only Huawei AF23 Sharing Dock)

The unlocked Huawei AF23 is compact enough to be carried in your bag. It comes with a USB port, four LED indicators, ethernet and micro-USB ports on the sides, and a reset button on the base. With the AF23, you can let 3G modem or 4G LTE modems to work as a 3G/4G router by simply plug the 3G/4G dongle into it. It is a good tool to enable you to share a 3G or 4G mobile network with numerous WiFi devices. Huawei af23 all sides. The AF23 Huawei has two antennae and boasts up to 300Mbps data transmission. It supports 802.11b/g/n, up to 32 wireless connections, and wireless encryption of WEP, WPA, WPA2, TKIP, and AES. This Huawei dock is so powerful that it could operate with 3 different modes: ethernet adapter mode, repeater mode, and LTE sharing mode. In repeater mode, just choose a wireless signal you want to enhance on the FW page then the AF23 will extend its signal coverage. The ethernet adapter mode can connect any Ethernet-enabled device to your wireless home network with LTE AF23 dock. The LTE sharing mode can let your LTE mobile modem to works as a 4G mobile hotspot.
After a long time, HUAWEI offered a new router again– the AF23, which can help a number of users to surf the Internet with Huawei 3G & 4G surf sticks via LAN or WLAN. Huawei AF23 has no built-in modem, so it must operate with a USB surf stick. We must pay attention to the highest possible speed of the HUAWEI AF23: the amazingly small router provides speeds of up to 300 Mbit/s over Wi-Fi and it’s also suitable for excellent Huawei LTE sticks.
Huawei AF23 is not as expensive as a wireless router. Huawei AF23 is not integrated with a battery that keeps the price low, but the HUAWEI AF23 can’t work as a mobile 4G router like HUAWEI E5776. So it’s better to use the HUAWEI AF23 as a stationary router. The English Short Guide describes the basic features, no further information is provided.
Huawei AF23 supports two modes of operation:
Work as a pure access point with the DSL or cable connection via WAN port on the back
